MODEL OK 520

TECHNICAL DATA

Overall length (m.)   5,14
Overall width (m.)   2,19
Inside size (cm.)   123x400
Weight (kg.)   290
Fabrics tubes   neoprene classic style
Number of air chambers   5
Diameter of tubes (cm.)   54
Working pressure bar (atm.)   0,20
Hull   twinshell
Person capacity   8
Testing power max. (Hp.)   90
Suggested power (Hp.)   70
Transom height (mm.)   508
Type approval design category CE   C

LOMAC advises that for the figures relative to weights and measures there could be a variation of +/- 3%

LOMAC reserves the right to change model characteristics at any time without notice.

STANDARD EQUIPMENT

  • drive console with steering system wheel
  • mechanic steering, reinforced
  • panel with 6 switches + 6 fusible
  • windshield and inox handrail
  • helm passenger and driver seat
  • rubber cleat only for standard version
  • grpf bow roller only for limited edition
  • inox ladder
  • table with leg
  • oars or paddle, inflation pump and repair kit

ACCESSORIES

  • fixed plastic  fuel tank lt. 55
  • sundeck bow
  • roll bar inox diam. 40
  • roll bar with bimini integrated
  • courtesy lights on roll bar
  • parasol awning alluminium D17
  • night cover
